Boom Lift suppliers Model Type No.CSTBL-12CSTBL-16CSTBL-20CSTBL-22CSTBL-26CSTBL-28CSTBL-30CSTBL-32CSTBL-36CSTBL-38CSTBL-42CSTBL-56 Max Working Height14.3m18.2m22.3m24.1 m28m30m32.4 m34 m38.64 m40.4 m44 m58m Max Platform Height12.3m16.2m20.3m22.1 m26m28m30.4m32 m36.64 m38.4 m42 m56m Max Working Radius10.5m15m18m18 m22m22m21.4 m21.4 m21.4 m21.4 m23 m26m Lift Capacity(restricted)480kg480kg480 kg480 kg480 kg480 kg480 kg480kg480 kg480 kg480 kg480kg Lift Capacity(non-restricted)230kg230kg230kg230 kg230kg230kg340 kg230 kg340 kg230 kg230 kg230kg Length( stowed) 鈷?/p>7.54m7.9m9.3m10.97 m11.55m13.5m13 m14.1 m13 m14.1 m13.3 m14.9m Width (stowed) 鈷?/p>2.29m2.39m2.49m2.49m2.5m2.5m2.5 m2.5 m2.5m2.5 m2.49 m5.1m Height(stowed) 鈷?/p>2.39m2.69m2.75m2.75 m2.83m2.83m3.08m3.08m3.08m3.08m3.28m3.6m Wheel Base 鈷?/p>2.45m2.45m3m3m3m3m3.66m3.66m3.96m3.96m3.96m5.6m Ground Clearance 鈷?/p>0.43m0.43m0.43m0.43 m0.43m0.43m0.43m0.43 m0.43m0.43m0.43 m0.43 m Platform Size鈷?鈷?/p>1.83*0.76m1.83*0.76m1.83*0.76m1.83*0.76m2.44*0.91m2.44*0.91m2.44*0.91m2.44*0.91m2.44*0.91m2.44*0.91m2.44*0.91m2.44*0.91m Turning radius( inside)2.2 m2.66m3m3m3.59 m3.59 m2.74 m2.74 m3.13 m3.13 m3.13 m3.13m Turning Radius(outside)5.2 m5.66m3m3 m5.59 m5.59 m4.14 m4.14 m4.14 m4.14 m4.14 m7.6m Travel Speed(stowed)4.4 km/h4.4km/h4.4km/h4.4 km/h4.4 km/h4.4 km/h4.4 km/h4.4 km/h4.4 km/h4.4 km/h4.4 km/h4.4km/h Travel Speed(raised )1.1 km/h1.1km/h1.1km/h1.1km/h1.1km/h1.1 km/h1.1km/h1.1km/h1.1km/h1.1km/h1.1km/h1.1km/h Grade Ability40%40%40%40%40%40%40%40%40%40%40%40% Solid Tire36脳12-2033脳12-2036脳14-2036脳14-20385/65-24385/65-24385/65-24385/65-24385/65-24385/65-22.5445/65-22.5445/65-22.5 Platform LevelingAutomatic leveling Swing Speed0~1/3rpm0~1/3rpm0~1/3rpm0~1/3rpm0~1/3rpm0~1/3rpm0~1/3rpm0~1/3rpm0~1/3rpm0~1/3rpm0~1/3rpm0~1/3rpm Turn Table Swing360掳 Continuous Platform Rotation卤80掳卤80掳卤80掳卤80掳卤80掳卤80掳卤80掳卤80掳卤80掳卤80掳卤80掳卤80掳 Fuel tank Capacity151L150L150L151 L151L151L151 L151 L151 L151L200L300L Total Weight7000kg10000kg12500kg13000 kg16500kg17000kg18500kg18650kg20120kg23000 kg23600kg27500kg Control Voltage12 V DC12 V DC12 V DC12 V DC12 V DC12V DC12 V DC12 V DC12 V DC12 V DC12 V DC24v EngineYanmarYanmarYanmarYanmarCumminsCumminsCumminsCumminsCumminsCumminsCumminsCummins Loading/Shipping40GP40FR40FR OWOH40FR OWOH40FR OWOH40FR OOG40FR OOG40FR OOG40FR OOG40FR OOG40FR OOG40FR OOG Drive*Steering4WD*2WS / 4WD*4WS (WD: wheel drive,WS: wheel steering) Product technical performance advantages: Full-scale gradient control - Full-scale gradient control of travel, boom lift, boom telescopic and rotating chassis makes the aerial work vehicle easy to position and operate more smoothly even in tight environments. Driving Confirmation System - Enhances operator alertness and safety. When the arm turns over the non-steering wheel, the travel action cannot be operated and an indicator light on the platform operation panel is on, and the direction of travel movement may be opposite to that of the elephant movement. At this time, the driving confirmation switch must use the resume driving function to ensure that the operator knows the position of the arm and the correct driving direction of the handle. Provides two seat belt hooks Foot switch - control all function power. The foot must be off the foot switch to start the engine. Automatic platform leveling - the platform automatically remains level when the boom angle changes. When the platform tilts more than 2 degrees, an alarm is issued, and when the platform tilts more than 3 degrees, the system cuts off the boom lift function and platform leveling function to protect the operator's safety. All functions on the control panel are indicated by easy-to-understand pictograms. Hydraulic system Hydraulic components - drive pumps and travel motors are products of internationally renowned companies. Full Pressure Hydraulic Filtration - Hydraulic filtration outside the pump (tank) and oil return filtration. Closed-Cycle Hydraulic Ride Circuit鈥擯rovides Unmatched Power and Performance. This load sensing system automatically adjusts the pump output to maintain optimum performance. The travel system circuit uses state-of-the-art axial variable displacement piston pumps and piston travel motors. Hydraulic System Modules - Provides reliability while improving maintainability and troubleshooting. Hydraulics are combined into four hydraulic modules for boom function, travel drive function, steering function, diverter function, platform function and auxiliary drive function, increasing reliability while reducing hoses, fittings and possible leaks. Diagnostics, troubleshooting and serviceability improve hydraulic and traditional piping systems. The module also features quick diagnostic connectors and spool interchangeability. 151L Hydraulic Tank - Provides a cooled hydraulic system to extend component life. The hydraulic oil tank has an oil level gauge, a temperature gauge, an absorption strainer, a return oil filter and a filter bypass gauge. This unit provides a cooled hydraulic system to extend component life, enhance corrosion resistance and improve monitoring system performance. Hydraulic Oil Cooler - It operates in the return circuit of the hydraulic travel and is cooled by the motor fan. Additional hydraulic oil cooling is available when the machine is operating in hot climates or when the job site requires extended travel. 鈼?Advanced harsh environment components Provides the industry's best protection for machines operating in dusty, abrasive, spray and corrosive environments. It includes oil cylinder bellows sheath, arm sand scraping device, control box protection box, center turntable box, engine air intake pre-filtering device and other configurations to provide protection for the machine that performs sand washing and spraying operations. 鈼?Igniter and repeated ignition protection system Protect the engine flywheel ring gear and starter motor. 鈼?Automatic engine shutdown The engine automatically shuts off when the engine temperature is too high or the oil pressure is too low. 鈼?The movable cover plate makes maintenance convenient Maintenance personnel can easily access the internal structure of the machine. 鈼?Pins and bushings Easy maintenance and long life use. All moving pins use treated steel pins and self-lubricating bearings; no yellow grease is required. After periodic experiments, it can withstand 10 years of normal use. 鈼?Control panel In order to adapt to the use environment with more welding slag splash and dust, we have changed the panel of the touch-type mask to a steel panel. 鈼?Length detector A sensor is installed inside the tail of the boom to detect the extension length of the boom by detecting the oil cylinder, which not only reduces the occurrence of faults, improves the reliability, but also reduces the damage caused by human error. Main Configuration: Basket (side swing 卤90掳) Proportional control handle:SAUER DANFOSS USA Program controller: EPEC Finland Length angle sensor: BPE Italy Hydraulic valve: Oil-control: Italy Hydroforce: United States Pump station: SAUER DANFOSS USA Salami Italy Swing motor: HELAC USA Walking reducer: Brevini Italy PMP Italy Omni USA Engine: Cummins USA Real Order:Boom Lift suppliers website:http://www.cathaylift.com/boom-lift/
